Description
| Mfr # | 907733 |
| Promotion Restriction | Not eligible for promotion |
| Item | Engine-Driven Welder |
| Series | Big Blue 400 Pro |
| Start Type | Electric |
| Rated Output CC/DC | 300A @ 32V, 100% / 325A @ 28V, 100% |
| Amperage Range | 20 to 400 |
| Continuous Auxiliary Power | 10,000 W |
| Peak Auxiliary Power | 12,000 W |
| Engine Brand | Mitsubishi |
| HP | 24.7 hp |
| Fuel Type | Diesel |
| Phase | 3 |
| TIG Welding Minimum Output Current | 20 A |
| Coolant Tank Capacity | 6 qt |
| Generator Fuel Type | Diesel |
| Stick Welding Maximum Output Current | 400 A |
| Generator Outlet Type | 14-50R, 5-20R |
| Horsepower | 25 hp |
| Stick Welding Minimum Output Current | 20 A |
| Sound Level | 68.7 dB (Idle), 72.1 dB (Weld) |
| Open Circuit Voltage | 85 V DC |
| MIG Welding Maximum Output Current | 400 A |
| Generator Outlets | 20 A 120V GFCI 5-20R (4), 50 A 120/240V 14-50R |
| For Material Type | Stainless Steel, Steel |
| Horsepower Range | 15 hp – 30 hp |
| Fuel Tank Capacity Range | 10 gal – 20 gal |
| Max. Amperage Range (Stick) | Greater than 300 A |
| Rated Output at Duty Cycle (Stick) | 300 A @ 100%, 350 A @ 100%, 400 A @ 100% |
| Oil Capacity | 6 qt |
| Engine Model | Mitsubishi S4L2 |
| Stick Welding Output @ Duty Cycle | 300 A @ 32 V, 100%, 350 A @ 27 V, 100%, 400 A @ 24 V, 100% |
| TIG Welding Maximum Output Current | 400 A |
| Polarity | DC |
| Circuit Breaker | Yes |
| Fuel Tank Capacity | 11.5 gal |
| MIG Welding Output @ Duty Cycle | 300 A @ 32 V, 100%, 350 A @ 27 V, 100%, 400 A @ 24 V, 100% |
| TIG Welding Output @ Duty Cycle | 300 A @ 32 V, 100%, 350 A @ 27 V, 100%, 400 A @ 24 V, 100% |
| Welding Mode | CC/CV |
| Welder Type | Base Model |
| Weight | 993 lb |
| Model | 907733 |
| Welder Model Type | Base Model |
| brand-mfr model | MILLER ELECTRIC – 907733 |
| Process | Air Carbon Arc Cutting and Gouging (CAC-A), Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW) |
