Description
| Mfr # | 907760 |
| Promotion Restriction | Not eligible for promotion |
| Item | Engine-Driven Welder |
| Series | Bobcat(TM) |
| Start Type | Electric |
| Rated Output CC/DC | 210A @ 25V, 100% |
| Amperage Range | 30 to 210 |
| Continuous Auxiliary Power | 6,200 W |
| Peak Auxiliary Power | 10,000 W |
| Engine Brand | Kubota |
| HP | 19 hp |
| Fuel Type | Diesel |
| Phase | 1 |
| Generator Outlet Type | 14-50R, 5-20R |
| Engine Model | Kubota D722 |
| Generator Outlets | 20 A 120V GFCI 5-20R (4), 50 A 120/240V 14-50R |
| Fuel Tank Capacity Range | Less than 10 gal |
| Remote Connection Type | 10-Pin (Miller) |
| Stick Welding Output @ Duty Cycle | 120 A @ 25 V, 100%, 140 A @ 26 V, 60%, 210 A @ 28 V, 20% |
| Horsepower | 19 hp |
| Welder Type | Base Model |
| MIG Welding Maximum Output Current | 210 A |
| MIG Welding Minimum Output Current | 30 A |
| Air Compressor Delivery | 30 CFM |
| Generator Fuel Type | Diesel |
| Maximum Pressure – Air Compressor | 175 psig |
| Color | Blue |
| Polarity | DC |
| Oil Capacity | 3 13/32 qt |
| TIG Welding Maximum Output Current | 210 A |
| Sound Level | 67 dB @ 23 ft (Idle), 73 dB @ 23 ft (Weld) |
| Weight | 618 lb |
| TIG Welding Output @ Duty Cycle | 120 A @ 25 V, 100%, 140 A @ 26 V, 60%, 210 A @ 28 V, 20% |
| Stick Welding Maximum Output Current | 210 A |
| TIG Arc Start Feature | Lift Arc Start |
| Rated Output at Duty Cycle (Stick) | 120 A @ 100%, 140 A @ 60%, 210 A @ 20% |
| Horsepower Range | 15 hp – 30 hp |
| TIG Welding Minimum Output Current | 30 A |
| Max. Amperage Range (Stick) | 150 A – 300 A |
| MIG Welding Output @ Duty Cycle | 120 A @ 20 V, 100%, 140 A @ 21 V, 60%, 210 A @ 25 V, 20% |
| Fuel Tank Capacity | 7 gal |
| Circuit Breaker | Yes |
| Stick Welding Minimum Output Current | 30 A |
| Welding Mode | CC/CV |
| Model | 907760 |
| Welder Model Type | Base Model |
| brand-mfr model | MILLER ELECTRIC – 907760 |
| Process | Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW) |
