Description
XE-R 242/240 Hyd Roller Cam Ford Mod 4-V
Race or limited street use. Cams require a larger throttle body, mass air, injectors, exhaust upgrades and requires custom tuning. Automatics need a 3000+ stall. Very rough idle.
| UPC | 036584097044 |
|---|---|
| Manufacturer | COMP Cams |
| Warranty | 12 Months |
| Emissions Code | |
| Engine Family | Ford 4.6L, 5.4L and 5.8L DOHC Modular 4 Valve 8 Cylinder (1993+) |
| RPM Operating Range | 2,200-6,500 |
| Cam Type | Hydraulic Roller Swinging Follower |
| Camshaft Series | Xtreme XE-R |
| Camshaft Gear Attachment | 1-Bolt |
| Usage | Street/Performance |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Advertised Intake Duration | 277 |
| Advertised Exhaust Duration | 275 |
| Intake Duration at .050 Inch Lift | 242 |
| Exhaust Duration .050 Inch Lift | 240 |
| Intake Valve Lift | 0.475 |
| Exhaust Valve Lift | 0.45 |
| Lobe Lift Intake | 0 |
| Lobe Lift Exhaust | 0 |
| Lobe Separation | 114 |
| Intake Centerline | 112 |
| Valve Timing Lift | 0 |
| Exhaust Close ATDC | 0 |
| Intake Open BTDC | 0 |
| Exhaust Open BBDC | 0 |
| Intake Close ABDC | 0 |
| Make | Ford |
| Engine | 4.6L, 5.4L and 5.8L DOHC Modular 4 Valve 8 Cylinder (1993+) |
| Lifter Type | Hydraulic Roller Swinging Follower |
| Usage | Street, Street / Strip |
