Edelbrock Stg 1 SC #15354 For 12-14 Jeep Grand Cherokee SRT/SRT8 6.4L W/ Tune
The Edelbrock Supercharger System part #15354 is designed for your 2012-14 6.4L HEMI Jeep Grand Cherokee SRT. The part #15354 kit made 471whp and 502wtq. Featuring a unique design with minimal components makes it possible to fit an Edelbrock supercharger under the stock hood. The core of each system is the Eaton Gen VI R2650 Supercharger rotating assembly with a four-lobe design with 170 degrees of twist for maximum flow, minimum temperature rise and quiet operation for excellent drivability. This supercharger features our DUAL PASS, 3 CORE (DP-3C) intercooler system. We also designed our superchargers with an integrated bypass valve to help eliminate parasitic loss under light throttle, improving mileage potential. Our unique and efficient inlet configuration results in a shorter, less restrictive intake path for improved airflow, without the need for a jack-shaft. Keeping the air cool is a high-capacity air-to-water intercooler and low-temp heat exchanger. For safety, the Edelbrock-supplied program will retain the factory vehicle speed limiter setting.
| Part Type | Supercharger Kit |
|---|---|
| Manufacturer | Edelbrock |
| Application | Application Specific |
| UPC | 085347153541 |
| System Type | Stage 1 – Street System |
| Vehicle Model | Cherokee |
| Grade Type | Performance |
| Housing Material | Cast Aluminum |
| Gasket Or Seal Included | Yes |
| Quantity | Kit |
| Oil Capacity | 150 mL |
| Center Housing Cooling Type | Intercooler |
| Internal Step Up | Yes |
| Mounting Bracket Included | Yes |
| Outside Pulley Diameter | 3.25 in |
| Maximum Torque | 502RW (With 93 Octane) ft-lb |
| Fuel Injector Type | 60 lb/hr |
| Maximum Horsepower | 471RW (With 93 Octane) |
| Availability Note | Available to Order |
| Warranty | 36 Months |
| Emissions Code | EO Number: D-215-114 |
| Application Summary | Chrysler:Gen III HEMI:392 (6.4L) |
| Hazardous Materials Warning |  WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Finish | Black Powder Coated |
| Inside Diameter | 1.251 in |
| Maximum Boost Pressure | 14 PSI |
| Outside Diameter | 3.875 in |
| Pulley Belt Width | 6-Rib |
