Edelbrock 7140 Pro-Flo XT EFI Intake Manifold for GM Gen IV LS2 Small-Block Chevy

Description

Pro-Flo XT Small Block Chevy LS2 EFI Intake Manifold
Edelbrock part #7140 Pro-Flo XT LS2 EFI intake manifold is engineered with a large plenum and tapered runners to deliver maximum horsepower and broad torque band throughout the rpm range (1500-7000 rpm). Features a 90mm throttle bore opening and 2.75″ port exit height. This manifold produced 30 more horsepower over a stock LS6 manifold at 6500 rpm. This Pro-Flo XT LS2 intake manifold accepts GM OEM 90mm or Edelbrock #3869 throttle bodies. Compatible with LS1 Fuel Rail Kit #3629 (sold separately), which features -6 AN inlet and outlet.

UPC	085347071401
Series	Pro-Flo XT
Material	Aluminum
Finish	Satin
Grade Type	Performance
Gasket Or Seal Included	No
Vehicle Model	Chevrolet
Availability Note	Available to Order
Warranty	12 Months
RPM Range	1500-7000 RPM
Emissions Code
Hazardous Materials Warning	WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Installation Notes	Recommended intake gasket: LS1/LS6 style individual port o-ring seals or Edelbrock #7386; Port exit dimensions: 1.04″x 2.74″; Manifold Dimensions: A-10.20″, B-10.00″, C-16.90″, D-3.2″, E-15 Deg; The throttle body centerline is located 6.75″ above the valley plate and 2.5″ forward of the first manifold hold-down bolt; Fits the factory 90mm LS2 throttle body; 90mm single throttle bore opening; Accepts Edelbrock #3869 or #38693 90mm Pro-Flo XT Throttle body; Edelbrock #3629 LS1 XT Fuel Rail kit including provisions for either Pico or standard height injectors (available separately); Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS.; Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.; Sealant must be used on intake bolt threads if the threads extend into lifter valley or coolant passage.; NPT/Pipe thread fittings require the use of Teflon tape or paste on threads to ensure proper seal.; DO NOT OVERTIGHTEN NPT/Pipe fittings, this may cause the aluminum to crack around the fitting boss. NPT/Pipe thread is a tapered thread.; To ensure maximum performance and a proper seal, Edelbrock gaskets which are specifically designed and manufactured for use with Edelbrock parts must be used.; Proper installation is the responsibility of the installer. Improper installation will void your warranty and may result in poor performance and engine or vehicle damage.
Color	Satin
Rear Maximum Height	10.000 in
Single Or Dual Plane Type	Single
