Edelbrock 7524 Performance Intake Manifold for Gen II Chrysler Hemi with Dual-Carburetor Setup

Description

Edelbrock part #7524 Dual-Quad HEMI intake manifold is intended for use with Mopar Gen II (1964-71) 426-572 HEMI engines operating in the 2,500 to 6,500+ range. This new intake manifold is a single-plane Air-Gap design with a dual square-bore 4150 style carburetor pad. Carburetor spacing and height are the same as Mopar Performance dual-quad #P5153737, making it a direct bolt-on to all vehicles with a shaker hood. They also retain the same carburetor linkage location from the factory. The Dual-Quad HEMI is compatible with factory style cylinder heads, but optimized for use with Edelbrock Victor Jr. HEMI cylinder heads. Requires Edelbrock Coil Bracket #8079 for use with OE style coils.

UPC	085347075249
Series	Dual-Quad/Multi Carb
Material	Aluminum
Finish	Satin
Grade Type	Performance
Gasket Or Seal Included	No
Vehicle Model	Chrysler
Availability Note	Available to Order
Warranty	12 Months
RPM Range	2500-6500 RPM
Emissions Code
Hazardous Materials Warning	WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Installation Notes	Recommended intake gasket: Edelbrock #7278; Manifold height: A-4.68″, B-5.51″; Carb pad height: 5.10″; Carb recommendations: Edelbrock AVS2 or Performer Series 600-800 cfm.; Throttle body recommendations: Edelbrock #38783 with progressive linkage #7094; Port exit dimensions: 1.80″ x 1.98″; Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS.; Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum.
Color	Satin
Rear Maximum Height	5.510 in
Single Or Dual Plane Type	Single
