High-performance Edelbrock 2890 Super Victor intake manifold designed for Chevrolet LS7 engines, featuring a Dominator-style carburetor flange for maximum airflow and throttle response

Description

Edelbrock Super Victor LS7 Dominator Flange Carburetor Intake ManifoldSuper Victor Small-Block Chevy LS7 Dominator Flange Carburetor Intake Manifold
Edelbrock part #2890 Super Victor LS7 intake manifold is designed for Gen IV LS engines equipped with LS7 cylinder heads or Edelbrock Pro-Port Victor Jr. cylinder heads. This manifold is .75″ taller than our LS3 Super Victor intakes. The new Super Victor intake manifold #2890 4500 Series carburetors has an increased intake runner area and is capable of 800+ hp operating in the 3,500-8,000 rpm range. A carburetor mounted style throttle bracket is recommended.

UPC	085347028900
Series	Victor
Material	Aluminum
Finish	Satin
Grade Type	Performance
Gasket Or Seal Included	No
Vehicle Model	Chevrolet
Availability Note	Available to Order
Warranty	12 Months
RPM Range	3500-8000 RPM
Emissions Code
Hazardous Materials Warning	WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov.
Installation Notes	Recommended intake gasket: Edelbrock #9746, LS7 style individual port o-ring seals GM PN89017852; Uses standard intake Edelbrock bolt kit #8515; Manifold height: A-8.42, B-8.42″; Carb pad height: 8.42″; Carb height (CH) for this manifold is measured from the valley cover flange to the carb pad.; Carb recommendations: Use appropriate 4500 Series racing carburetor; Port exit dimensions machine matched: 1.34″ x 2.38″
Color	Satin
Rear Maximum Height	8.420 in
Single Or Dual Plane Type	Single
