Single Conical Ovate Valve Spring – Precision-Wound For High-Lift Cams

Description

Valve Springs Single Conical Ovate Wire top OD 1.055″, ID .650″, bttm OD 1.250″

Rate/inch 349 lbs, 113 lbs @ 1.750″, 302 lbs @ 1.200″, Coil Bind @ 1.100″

C68155-16

8155-16

Spring O.D/I.D Top: 1.055″/.650″Spring O.D.I.D Bottom: 1.250″/.845″Seat Load: 113 @ 1.750″Open Load: 126 @ 1.150″Coil Bind: 1.100″Rate (LBS/In): 349 lbsMax Lift: .650″
