SPDT Rocker Switch for Start/Stop Control

Description

Mfr # 001-330. Rocker Switch , UL Recognized and CSA Certified, Single Pole Non-Illuminated, Snap-in Mounting, Replacement Switches for Paneltronics’ Deluxe and Premier Panels, , Specifications: , Maximum Contact Rating: 6 Amps @ 125VAC or 4 Amps @ 250VAC, Contacts: Silver Plated Copper, Terminals: Silver Plated Copper 1/4″ (6.3mm) Quick Connects, Operating Temperature: -4 deg F (-20 deg C) to 131 deg F (55 deg C), Housing and Actuator: Black Thermoplastic, Flammability Rating: UL 94 V-2, Rated IEC 60529: IP40, Panel Thickness: 1/8″ (3.18mm), Recommended Panel Cut-Out: 1.188″ (30.18mm) x 0.468″ (11.89mm).
