Description
| Mfr # | 907549001 |
| Promotion Restriction | Not eligible for promotion |
| Item | Engine-Driven Welder |
| Series | Trailblazer 302 Air Pak |
| Start Type | Electric |
| Rated Output CC/AC | 200A @ 25V, 60% |
| Rated Output CC/DC | 280A @ 32V, 100% |
| Amperage Range | 10 to 350 |
| Continuous Auxiliary Power | 11,000 W |
| Peak Auxiliary Power | 13,000 W |
| Engine Brand | Kohler |
| HP | 30 hp |
| Fuel Type | Gas |
| Phase | 1 |
| Includes | Air Compressor, Battery Charge/Jump Start. |
| Fuel Tank Capacity | 12 gal |
| Max. Amperage Range (Stick) | 150 A – 300 A |
| TIG Welding Minimum Output Current | 10 A |
| Circuit Breaker | Yes |
| Horsepower Range | 15 hp – 30 hp |
| Remote Connection Type | 14-Pin (Miller) |
| Stick Welding Output @ Duty Cycle | 200 A @ 25 V, 60%, 280 A @ 32 V, 100% (DC) |
| Maximum Pressure – Air Compressor | 160 psig |
| Generator Fuel Type | Gasoline |
| TIG Welding Output @ Duty Cycle | 200 A @ 25 V, 60%, 280 A @ 32 V, 100% (DC) |
| Rated Output at Duty Cycle (Stick) | 200 A @ 60%, 280 A @ 100% |
| Welder Type | Base Model |
| Polarity | AC/DC |
| For Material Type | Aluminum, Stainless Steel, Steel |
| Horsepower | 27 hp |
| MIG Welding Maximum Output Current | 350 A |
| Weight | 771 lb |
| Welding Mode | CC/CV |
| Color | Blue |
| Sound Level | 73.4 dB (Idle), 81.2 dB (Weld) |
| Generator Outlets | 20 A 120V GFCI 5-20R (4), 50 A 120/240V 14-50R |
| Engine Model | Kohler CH750 |
| MIG Welding Output @ Duty Cycle | 300 A @ 32 V, 100%, 350 A @ 32 V, 60% |
| Stick Welding Minimum Output Current | 10 A |
| Air Compressor Delivery | 22 CFM @ 2400 RPM (Idle), 28 CFM @ 3000 RPM, 31 CFM @ 3600 RPM |
| Stick Welding Maximum Output Current | 300 A |
| TIG Welding Maximum Output Current | 300 A |
| Fuel Tank Capacity Range | 10 gal – 20 gal |
| Oil Capacity | 1 3/4 qt |
| Generator Outlet Type | 14-50R, 5-20R |
| Model | 907549001 |
| Process | Air Carbon Arc Cutting and Gouging (CAC-A), Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW) |
| Welder Model Type | Base Model |
| brand-mfr model | MILLER ELECTRIC – 907549001 |
