Description
XE 236/240 Ford 4.6/5.4L Modular 2-V
Hot street, 3.55-3.73 gears, 2000+ stall. Requires custom tuning. Rough idle.
| UPC | 036584072409 |
|---|---|
| Manufacturer | COMP Cams |
| Warranty | 12 Months |
| Emissions Code | |
| Engine Family | Ford 4.6L and 5.4L SOHC Modular 2 Valve 8 Cylinder (1991+) |
| RPM Operating Range | 2,000-6,000 |
| Cam Type | Hydraulic Roller Finger Follower |
| Camshaft Series | Xtreme Energy |
| Camshaft Gear Attachment | 1-Bolt |
| Usage | Street/Performance |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Advertised Intake Duration | 274 |
| Advertised Exhaust Duration | 278 |
| Intake Duration at .050 Inch Lift | 236 |
| Exhaust Duration .050 Inch Lift | 240 |
| Intake Valve Lift | 0.5 |
| Exhaust Valve Lift | 0.5 |
| Lobe Lift Intake | 0.274 |
| Lobe Lift Exhaust | 0.274 |
| Lobe Separation | 114 |
| Intake Centerline | 110 |
| Valve Timing Lift | 0.05 |
| Exhaust Close ATDC | 2 |
| Intake Open BTDC | 7 |
| Exhaust Open BBDC | 57 |
| Intake Close ABDC | 48 |
| Make | Ford |
| Lifter Type | Hydraulic Roller Finger Follower |
