Description
XE 226/230 Ford 4.6/5.4L Mod 2-V PI Head
Excellent torque. Better low and mid-range torque with more power. Will work with stock computer, best with custom tuning.
| UPC | 036584072614 |
|---|---|
| Manufacturer | COMP Cams |
| Warranty | 12 Months |
| Emissions Code | |
| Engine Family | Ford 4.6L and 5.4L SOHC Modular 2 Valve 8 Cylinder (1991+) |
| RPM Operating Range | 1,400-5,400 |
| Cam Type | Hydraulic Roller Finger Follower |
| Camshaft Series | Xtreme Energy |
| Camshaft Gear Attachment | 1-Bolt |
| Usage | Street/Performance |
| ECU Tune Required? | Recommended |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Advertised Intake Duration | 262 |
| Advertised Exhaust Duration | 266 |
| Intake Duration at .050 Inch Lift | 226 |
| Exhaust Duration .050 Inch Lift | 230 |
| Intake Valve Lift | 0.55 |
| Exhaust Valve Lift | 0.55 |
| Lobe Lift Intake | 0.3 |
| Lobe Lift Exhaust | 0.3 |
| Lobe Separation | 113 |
| Intake Centerline | 109 |
| Valve Timing Lift | 0.05 |
| Exhaust Close ATDC | -2 |
| Intake Open BTDC | 4 |
| Exhaust Open BBDC | 52 |
| Intake Close ABDC | 42 |
| Make | Ford |
| Lifter Type | Hydraulic Roller Finger Follower |
