Icon IC9985C.020 Forged Flat-Top Pistons — 3.800″ Bore, +0.020″ Oversize, for GM LS 4.8L and 5.3L Engines with 0.945″ Pin

Description

LS 5.3L FT Forged Piston Set 3.800 Bore
Upgrade your engine with the ICON PISTONS LS 5.3L FT Forged Piston Set, designed for performance and longevity. This set includes eight high-quality forged pistons tailored for GM LS-Series engines, ensuring optimal performance in high-stress conditions. Featuring a bore size of 3.800 inches and a ring groove configuration of 1.5 x 1.5 x 3.0 mm, these pistons are crafted to enhance your engine’s efficiency and power output.

Features:
* Bore Size: 3.800 inches for enhanced performance
* Ring Groove: 1.5 x 1.5 x 3.0 mm for improved sealing and efficiency
* Engine Compatibility: Specifically designed for GM LS-Series engines
* Piston Type: Forged construction for superior strength and durability
* Volume: Minus 2.90 cc for optimized compression ratios
* Set Includes: Eight pistons to complete your engine build

Bore (in.):3.800 in.Stroke:3.622 in.Engine Stroke Type:StockRod Length:6.098 in.Piston Style:Flat top, with two valve reliefsPiston Material:Forged aluminumCompression Height (in.):1.331 in.Piston Head Volume (cc):+2.90ccWrist Pin Style:Press-fit or floatingWrist Pin Retainers Included:YesWrist Pin Included:YesPin Diameter (in.):0.945 in.Piston Ring Thickness:1.50mm x 1.50mm x 3.00mm
